Shanxi Xinshunda Flange Manufacturing Co., Ltd. supplies high-precision EN1092-1 Type 13 hubbed threaded flanges engineered for medium-pressure piping systems requiring strong structure and non-welded installation. Fully compliant with EN1092-1, our Type 13 flanges combine the strength of a hubbed design with the convenience of threaded connection, ensuring stable sealing, high pressure resistance and long service life. With 19 years of forging and machining expertise, we provide reliable flange solutions to 3,800+ clients in over 70 countries worldwide.
Product Description
EN1092-1 Type 13 hubbed threaded flange is an integrated design with a reinforced hub and internal pipe threads. It combines high structural strength with threaded connection, eliminating welding while improving stress distribution and pressure bearing capacity. It is widely used in small-bore, non-weldable, hazardous, frequent maintenance or instrument piping systems. Our Type 13 flanges are precisely forged and CNC machined to ensure accurate thread fit, stable sealing and zero leakage under rated operating conditions.
Product Feature and Application
Key Features
- Reinforced hub design for higher strength and better stress distribution
- Internal thread connection, no welding required for installation
- Fast assembly and disassembly, convenient for inspection and maintenance
- High precision threads ensure tight fit and stable sealing
- Excellent pressure, vibration and fatigue resistance
- Full compliance with EN1092-1 dimensional standards
- Suitable for non-welded, flammable, explosive or hazardous environments
Main Applications
- Oil, gas and petroleum transmission pipelines
- Petrochemical, chemical and pharmaceutical processing lines
- Small-bore instrument and utility piping systems
- Compressed air, water, steam and fluid transmission networks
- Marine, offshore and boiler auxiliary systems
- Non-weldable, hazardous and frequent maintenance working conditions
Product Parameter (Specification)
| Standard | EN1092-1 Type 13 |
| Type | Hubbed Threaded Flange |
| Pressure rating | PN10, PN16, PN25, PN40 |
| Nominal diameter | DN10 – DN150 |
| Face type | Raised Face (RF), Flat Face (FF) |
| Surface roughness | Ra 1.6–3.2 μm (125–250 µin) |
|
Material |
Carbon steel: A105, P250GH, 1.0460, C22.8 Stainless steel: 1.4301 (304), 1.4401 (316), 1.4571 Alloy steel: 1.7335, 1.7357 |
| Thread standard | ISO 7/1, NPT, BSPT, BSPP (customizable) |
| Working temperature | −20 °C – 600 °C (material dependent) |
| Certification | EN 10204-3.1 Material Test Certificate |
Production Details
Each EN1092-1 Type 13 flange is manufactured under strict quality control:
- Raw material inspection with mill certification and spectral analysis
- Precision forging and controlled heat treatment for stable mechanical properties
- CNC machining for hub forming, threading and facing
- Sealing surface polishing to meet standard roughness requirements
- 100% dimensional inspection using CMM, gauges and thread testers
- Visual inspection, optional MT/UT non-destructive testing
- Hydrostatic pressure test to verify pressure safety and integrity
- Anti-corrosion oil coating and permanent marking
Production Display
Our factory is ISO 9001 certified with full sets of forging lines, CNC machining centers, specialized thread processing equipment and professional testing laboratories. The whole production process is traceable. We support third party inspection by SGS, BV, TÜV or other authorized institutions as customer request.
Packaging & Transportation
- Surface treatment: Anti-corrosion oil, varnish or black paint
- Packaging: Plastic film, woven bag, export-grade wooden case, steel pallet
- Labeling: Heat number, size, material, standard, pressure, batch, thread type
- Documents: Commercial invoice, packing list, certificate of origin, material test certificate
- Transportation: Sea, air, express delivery to over 70 countries
After-sales Service
We provide full life cycle support for EN1092-1 Type 13 flanges:
- Professional technical consultation on thread selection and installation
- Custom thread standards and sizes based on customer drawings
- Timely response to after-sales inquiries and quality claims
- Remote technical guidance and on-site support
- Long-term stable supply and inventory backup
Why Choose Us
- 19 years of professional flange manufacturing experience
- Full compliance with EN1092-1 and international standards
- High precision hub and thread processing
- Strict quality control and complete testing
- Direct factory price with reliable quality
- Multilingual service and global logistics support
Contact us now for catalog, quotation or customized solutions of EN1092-1 Type 13 hubbed threaded flanges.
