AS2129 Table J flange is a weld neck flange complying with Australian standard AS2129, designed for high-pressure and high-temperature service. It has a long tapered hub for butt-welding to pipes, effectively reducing stress and improving fatigue resistance. Our Table J flanges are widely used in oil, gas, water transmission, petrochemical and power plant pipelines.
Production Details
Each AS2129 Table J flange is manufactured under full-process quality control:
Raw material inspection with mill certificates and spectral analysis
Precision closed-die forging for optimized grain structure
Controlled heat treatment for stable mechanical properties
High-precision CNC machining for hub, face and bolt holes
100% dimensional inspection using calibrated gauges and CMM
Full NDT: magnetic particle testing (MT), ultrasonic testing (UT)
Hydrostatic pressure test to verify safety and integrity
Anti-corrosion oil coating and permanent marking
Full material traceability
Product Feature and Application
Key Features
- Fully compliant with AS2129 Table J standard dimensions
- Weld neck design reduces stress concentration
- High strength and excellent pressure resistance
- Butt weld structure ensures strong and leak-free connection
- High precision and full interchangeability
- Suitable for high-pressure and critical systems
- Long service life in harsh environments
Typical Applications
- High-pressure water transmission pipelines
- Oil, gas and petrochemical process systems
- Power plant boiler and steam pipelines
- Pumping stations and heavy industrial equipment
- Australian and New Zealand high-pressure projects
- Infrastructure and utility critical piping
| Standard | AS2129 Table J |
| Pressure Rating | High Pressure (Table J) |
| Nominal Diameter | DN15 – DN600 (15Nb – 600Nb) |
| Type | Weld Neck Flange |
| Face Type | Raised Face (RF) |
| Materials | Carbon steel A105, P250GH; Stainless steel 304, 316, 316L, Duplex 2205 |
| Working Temperature | −20 °C – 450 °C |
| Certification | EN 10204 3.1 Material Test Certificate |
Production Display
Our ISO 9001 certified factory is equipped with large-tonnage forging presses, high-rigidity CNC machining centers and professional NDT laboratories. Third-party inspection by SGS, BV, TÜV is available upon request.
Product Transport Package
- Surface Treatment: Anti corrosion oil, black paint or varnish
- Packaging: Plastic film, woven bag, export wooden case, steel pallet
- Labeling: Size, table, material, standard, heat number, batch
- Documents: Commercial invoice, packing list, certificate of origin, material test certificate
- Transportation: Sea, land and express delivery to global markets
After-sales Service
We provide full life-cycle technical support for AS2129 Table J flanges:
- Professional consultation on selection, welding and installation
- Custom sizes, materials and drilling per customer drawings
- Timely response to after-sales inquiries and quality claims
- Remote technical guidance and on-site support
- Stable long-term supply for large-scale projects
