AS2129 Table C flange is an ultra-low-pressure plate slip-on flange complying with Australian standard AS2129. It is the lightest pressure grade in the AS2129 series, suitable for ventilation, drainage, non-pressure fluid and utility pipelines. Our Table C flanges are precisely machined to ensure easy installation and good compatibility.
Production Details
Each AS2129 Table C flange is produced under strict quality control:
Raw material inspection with mill certificates and spectral analysis
Precision plate cutting per AS2129 standard
CNC machining for accurate dimensions, bolt holes and facing
100% dimensional inspection using calibrated gauges and CMM
Visual inspection for surface defects and finish
Anti-corrosion oil coating and permanent marking
Full material traceability
Product Feature and Application
Key Features
- Fully compliant with AS2129 Table C standard dimensions
- Ultra-low-pressure design for economical use
- Lightweight and easy to handle and install
- High precision and good interchangeability
- Smooth welding surface for convenient connection
- Suitable for non-pressure and low-load systems
- Cost-effective for large-scale projects
Typical Applications
- Ventilation and air conditioning systems
- Drainage and non-pressure water pipelines
- Utility and civil engineering piping
- Construction and general industry
- Australian and New Zealand low load projects
- Large-scale non-critical infrastructure
| Standard | AS2129 Table C |
| Pressure Rating | Ultra-Low Pressure (Table C) |
| Nominal Diameter | DN15 – DN600 (15Nb – 600Nb) |
| Type | Slip On Plate Flange, Blind Flange |
| Face Type | Flat Face (FF) |
| Materials | Carbon steel A105, S235JR; Stainless steel 304, 316 |
| Working Temperature | −20 °C – 200 °C |
| Certification | EN 10204 3.1 Material Test Certificate |
Production Display
Our ISO 9001 certified factory is equipped with full sets of plate processing, CNC machining and testing equipment. Full production process is traceable. Third-party inspection supported.
Product Transport Package
- Surface Treatment: Anti-corrosion oil, black paint or varnish
- Packaging: Plastic film, woven bag, export wooden case, steel pallet
- Labeling: Size, table, material, standard, heat number, batch
- Documents: Commercial invoice, packing list, certificate of origin, material test certificate
- Transportation: Sea, land and express delivery to global markets
After-sales Service
We provide full life-cycle technical support for AS2129 Table C flanges:
- Professional consultation on selection and installation
- Custom sizes, materials and drilling per customer drawings
- Timely response to after-sales inquiries and quality claims
- Remote technical guidance and on-site support
- Stable long-term supply for large-scale projects
Hot Tags: table c flange, China table c flange manufacturers, suppliers, factory
